Specifications
Configuration: 6 cylinders in line 4 stroke Diesel
Fuel system: Extra High Pressure Injection (XPI)
Displacement: 12.7 l [775 in³]
Bore & Stroke: 130 x 160 mm [5.1 x 6.3 in]
Air intake: Turbocharged with after cooler
Cooling: Closed cooling with heat exchanger and charge air cooler
Transmission: Shaft Line, Water Jet, Surface Drive
Emission: IMO Tier II, EU Stage IIIA
Dimensions
Max length: 1809 mm [71,2 in]
Length clutch: 1389 mm [54,7 in]
Width: 1073 mm [42,2 in]
Height: 1115 mm [43,9 in]
Weight: 1285 kg [2833 lbs]
Features and benefits
- Scania engine base
- High power density
- Robust design
- High torque at low RPM
- Optimized fuel consumption at maximum torque
- Replaceable wet-type cylinder liners
- Installation flexiblity
- Best in class on power to weight Ratio
