Specifications
Configuration: 8 cylinders in V 4 stroke Diesel
Fuel system: Extra High Pressure Injection (XPI)
Displacement: 16.4 l [1000.8 in³]
Bore & Stroke: 130 x 154 mm [5.1 x 6.1 in]
Air intake: Twin turbocharged with air-to-seawater aftercooler
Cooling: Closed cooling with heat exchanger and aftercooler
Transmission: Shaft Line, Water Jet, Surface Drive
Emission: IMO Tier II
Dimensions
Max length: 1362 mm [53.6 in]
Length clutch: 1278 mm [50,3 in]
Width: 1136 mm [44,7 in]
Height: 1660 mm [3659 in]
Weight: 1660 kg [3659.7 lbs]
Features and benefits
- Scania engine base
- High power density
- Robust design
- High torque at low RPM
- Optimized fuel consumption at maximum torque
- Replaceable wet-type cylinder liners
- Installation flexiblity
- Best in class on power to weight Ratio
