Specifications
Configuration: 6 cylinders in line 4 strokes Diesel
Fuel system: Electronically controlled unit injectors
Displacement: 13,6 l [830 in³]
Bore & Stroke: 132 x 165 mm [5,2 x 6,5 in]
Air intake: Turbocharged Air-to-seawater aftercooler
Cooling: Closed cooling with heat exchanger
Transmission: Shaft Line, Water Jet, Surface Drive
Emission: RCD2 2013/53/EU, EPA Marine Tier 3, IMO Marpol Annex VI, NRMM (97/68/EC) Tier 3
Dimensions
Max length: 1426 mm [56.1 in]
Length clutch: 1032 mm [40.6 in]
Width: 1143 mm [45 in]
Height: 1380 mm [3042 in]
Weight: 1380 kg [3042 lbs]
Features and benefits
- John Deere engine base
- Robust design
- High power density
- 4 valves per cylinder
- Installation flexiblity
- Replaceable wet-type cylinder liners
