Specifications
Configuration: 4 cylinders in line 4 strokes Diesel
Fuel system: Mechanical Indirect injection
Displacement: 2,434 l [148.5 in³]
Bore & Stroke: 87 x 102,4 mm [3,43 x 4,03 in]
Air intake: Turbocharged
Cooling: Closed cooling with heat exchanger
Transmission: Shaft Line, Sail Drive
Emission: IMO MARPOL Annex VI compliant, RCD2 2013/53/EU, EPA Marine Tier 3, BSO 2
Dimensions
Max length: 732 mm [28.8 in]
Length clutch: 697 mm [27.4 in]
Width: 505 mm [19.9 in]
Height: 632 mm [24.9 in]
Weight: 248 kg [546.75 lbs]
Features and benefits
- Kubota engine base
- High power density
- Extensive range of options
- Low fuel consumption
- Repowering made easy
- Low installation costs
- Gear driven valve train
- Easy routine servicing
- SOLAS approved version available
- Installation flexibility
