Specifications
Configuration: 6 cylinders in line 4 strokes Diesel
Fuel system: Direct injection Mecanical controlled
Displacement: 4,2 l [254 in³]
Bore & Stroke: 94 x 100 mm [3,7 x 3,94 in]
Air intake: Turbocharged with intercooler
Cooling: Closed cooling with heat exchanger
Transmission: Shaft Line, Water Jet
Emission: BSO 2
Dimensions
Max length: 1242 mm [48.9 in]
Length clutch: 989 mm [38.9 in]
Width: 669 mm [26.3 in]
Height: 756 mm [29.8 in]
Weight: 469 kg [1034 lbs]
Features and benefits
- Toyota engine base
- Robust design
- Compact package
- High power density
- Easy routine servicing
- Installation flexiblity
- 4 valves per cylinder
- Balancing shafts
