Specifications
Configuration: 4 cylinders in line 4 strokes Diesel
Fuel system: Mechanical Indirect injection
Displacement: 1,498 l [91 in³]
Bore & Stroke: 78 x 78,4 mm [3,07 x 3,09 in]
Air intake: Natural
Cooling: Closed cooling with heat exchanger
Transmission: Shaft Line, Sail Drive
Emission: RCD2 2013/53/EU, EPA Marine Tier 3, BSO 2
Dimensions
Max length: 749 mm [29.5 in]
Length clutch: 655 mm [25.8 in]
Width: 465 mm [18.3 in]
Height: 605 mm [23.8 in]
Weight: 139 kg [306 lbs]
Features and benefits
- Kubota engine base
- Robust design
- Low fuel consumption
- Low rated rpm
- High power density
- Installation flexibility
- Extensive range of options
- Low installation costs
- Easy routine servicing
- Gear driven valve train
- SOLAS approved version available
