Specifications
Configuration: 3 cylinders in line 4 strokes Diesel
Fuel system: Mechanical Indirect injection
Displacement: 1.123 l [68.5 in³]
Bore & Stroke: 78 x 78.4 mm [3.07 x 3.09 in]
Air intake: Natural
Cooling: Closed cooling with heat exchanger
Transmission: Shaft Line, Sail Drive
Emission: RCD2 2013/53/EU, EPA Marine Tier 3, BSO 2
Dimensions
Max length: 667 mm [26.2 in]
Length clutch: 570 mm [22.4 in]
Width: 467 mm [18.39 in]
Height: 589 mm [23.2 in]
Weight: 136 kg [300 lbs]
Features and benefits
- Kubota engine base
- Low fuel consumption
- Gear driven valve train
- Easy routine servicing
- Repowering made easy
- Installation flexibility
- Extensive range of options
- Low installation costs
- SOLAS approved version available
