Specifications
Configuration: 6 cylinders in line 4 strokes Diesel
Fuel system: Direct injection Mechanical governor
Displacement: 6,8 l [415 in³]
Bore & Stroke: 106,4 x 127 mm [4,19 x 5 in]
Air intake: Turbocharged
Cooling: Closed cooling with heat exchanger
Transmission: Shaft Line, Water Jet, Surface Drive
Emission: IMO MARPOL Annex VI compliant, EPA Marine Tier 3
Dimensions
Max length: 1152 mm [45.3 in]
Length clutch: 883 mm [34.8 in]
Width: 884 mm [34.8 in]
Height: 735 mm [1620 in]
Weight: 735 kg [1620 lbs]
Features and benefits
- John Deere engine base
- High power density
- Robust design
- Replaceable wet-type cylinder liners
- Installation flexiblity
