Specifications
Configuration: 4 cylinders in line 4 strokes Diese
Fuel system: Direct injection Mechanical governor electronically controlled
Displacement: 4,5 l [275 in³]
Bore & Stroke: 106,4 x 127 mm [4,19 x 5 in]
Air intake: Turbocharged Air-to-seawater aftercooler
Cooling: Closed cooling with heat exchanger
Transmission: Shaft Line, Water Jet
Emission: IMO MARPOL Annex VI compliant, RCD2 2013/53/EU, EPA Marine Tier 3, NRMM 97/68/EC
Dimensions
Max length: 885 mm [34.8 in]
Length clutch: 770 mm [30.3 in]
Width: 964 mm [37.9 in]
Height: 578 mm [1274 in]
Weight: 578 kg [1274 lbs]
Features and benefits
- John Deere engine base
- Robust design
- High power density
- Internal balancers
- Easy routine servicing
- Installation flexiblity
- Replaceable wet-type cylinder liners
