Specifications
Configuration: 4 cylinders in line 4 stroke Diesel
Fuel system: With Electronic Speed Governor
Displacement: 3,769 l [230 in³]
Bore & Stroke: 100 x 120 mm [3,94 x 4,72 in]
Air intake: Turbocharged with intercooler
Cooling: Closed cooling with heat exchanger
Transmission: Shaft Line, Sail Drive
Emission: RCD2 2013/53/EU, EPA Marine Tier 3, BSO 2
Dimensions
Max length: 960 mm [37.8 in]
Length clutch: 796 mm [31.3 in]
Width: 580 mm [22.8 in]
Height: 728 mm [28.7 in]
Weight: 350 kg [772 lbs]
Features and benefits
- Kubota engine base
- Low rated rpm
- Installation flexibility
- Low installation costs
- Easy routine servicing
- Gear driven valve train
- Extensive range of options
- Optimum fuel consumption
