The Manomètre inox à bain glycérine Radial 0 à 25 bars Ø63 1/4" is a high-performance pressure gauge designed for precise pressure measurement in industrial applications. Its glycerin-filled mechanism ensures stable readings by dampening vibrations and temperature fluctuations.
- Glycerin-Filled Mechanism: Reduces needle oscillations, providing stable and accurate pressure readings.
- Stainless Steel Construction: The AISI 304 stainless steel case offers exceptional resistance to corrosion, ensuring durability in harsh environments.
- Radial Connection: The 1/4" radial (lower) connection facilitates easy installation in confined spaces.
- Dual Scale Display: Features both bar and psi scales for versatile pressure readings.
Technical Specifications
- Pressure Range: 0 to 25 bars
- Diameter: 63 mm
- Accuracy Class: 1.6%
- Maximum Fluid Temperature: 60°C
- Ambient Temperature Range: -20°C to +60°C
- Connection Type: 1/4" BSP male thread
- Movement: Copper alloy
- Window: Polycarbonate
- Pointer: Black aluminum
Materials
- Case: AISI 304 Stainless Steel
- Bourdon Tube and Connection: Brass
- Window: Polycarbonate
- Pointer: Aluminum
Dimensions
- Case Diameter: 63 mm
- Depth: Approximately 50 mm
- Connection Size: 1/4" BSP male thread
Compatibility Information
This pressure gauge is suitable for use in various industrial applications, including:
- High-pressure industrial installations
- High-performance hydraulic systems
- Pressure vessels
- High-pressure water pumps
Ensure that the maximum pressure and temperature ratings are not exceeded to maintain accurate readings and prolong the gauge's lifespan.
