Molex 83614 25 Way Vertical D-sub Connector Plug, 1.27mm Pitch - 836149016

Number of Contacts = 25
Gender = Male
Body Orientation = Vertical
Mounting Type = PCB Mount
Pitch = 1.27mm
D Connector Type = Micro-D
Termination Method = Through Hole
Current Rating = 1A
Housing Material = Liquid Crystal Polymer
Voltage Rating = 350 V ac
Length = 30.1mm
Width = 15.26mm
Depth = 7.8mm
Dimensions = 30.1 x 15.26 x 7.8mm
Minimum Operating Temperature = -40.0°C

Molex Commercial Micro D-Sub PCB Mount Connectors. From Molex, the next generation in commercial Micro-D-Sub connectors. These Micro D PCB mount plugs are 4 times the density of standard D-Subs. An ideal space saving solution for the ever demanding industrial data markets. The robust connectors feature a metal interface and grounding tabs with a 1.27mm centre line spacing. Available in right angle and vertical options. Complete with jack posts. Features and Benefits. Improved space saving on PCB board Rugged robust design High density 1.27 mm pitch Metal interface and grounding tabs Wide operating temperature range -40°C to +125°C. Applications. Medical Industrial automation Data/communications Commercial Vehicle
