Moflash A2EX Series Metallic Stainless Steel Cable Gland, M20 Thread, 11mm min., 15mm max., IP66, IP68 - 50211

Thread Size = M20
Maximum Cable Diameter = 15mm
Minimum Cable Diameter = 11mm
Material = Stainless Steel
Colour = Metallic
Series = A2EX
IP Rating = IP66, IP68
Locknut Included = No
Hazardous Area Certification = ATEX
Maximum Operating Temperature = +95°C

ATEX, IECEx, INMETRO, SANS/IEC. A2EX Compression Gland for Explosive Atmospheres. The A2EX Compression Gland is designed for use with unarmoured cable in hazardous areas with a potentially explosive atmosphere. Equipment protection levels: Ex d IIC Gb, Ex e IIC Gb, Ex nR IIC Gc, Ex tb IIIC Db II 2G, II 2D, II 3G. For indoor, outdoor and hazardous areas for Group II surface installations Inner seal of seal seals on the cable sheath Outer seal grips the cable, giving superior cable retention and IP rating Precision manufactured from high quality brass (marine grade electroless nickel plated) or stainless steel Complete with a sealing gasket and end cap safety gauge for correct gland selection IP66 / IP68 protection
