Key Features:
- Advanced GPS Trolling System: Utilizes GPS to control the trolling motor with features like Spot-Lock, Drift Mode, and more.
- Spot-Lock with Jog: Holds the boat in place with GPS accuracy; includes a heading sensor for precise positioning.
- Drift Mode: Automatically controls speed and course to maintain desired drift, even in heavy wind and current.
- Digital Maximizer: Provides up to 5 times longer run time on a single battery charge by delivering only as much power as needed.
- Indestructible Composite Shaft: Guaranteed for life, ensuring durability and longevity.
- Lift-Assist System: Allows for easy deployment and stowing of the motor with minimal effort.
- One-Boat Network Compatibility: Connects with select Humminbird fish finders for integrated control.
Technical Specifications:
- Thrust: 80 lbs
- Voltage: 24V
- Shaft Length: 60 inches (152 cm)
- Shaft Diameter: 1.25 inches
- Weight: 50 lbs (22.68 kg)
- Dimensions (L x W x H): 72.25" x 15.63" x 9" (183.52 cm x 39.7 cm x 22.86 cm)
- Mounting Dimensions: 13.94" x 8.52"
- Mounting Hole Pattern: Compatible with standard Minn Kota mounting systems
- Control Options: Wireless remote control; foot pedal available separately
- Battery Requirements: Two 12V marine batteries wired in series
- Amperage Draw: 50 amps at maximum speed
- Run Time Estimates:
- 20+ hours at slow trolling speeds (5 amps or less)
- 4.8 hours at 50% throttle
- 2.4 hours at full throttle
Materials:
- Lower Unit Housing: Grit-blasted and coated in aluminum to prevent oxidation and rust, followed by a final layer of powder coat paint for ultimate protection.
- Shaft: Indestructible composite material, guaranteed for life.
Compatibility Information:
- Boat Compatibility: Suitable for boats up to 850 kg (approximately 1,874 lbs)
- Battery Compatibility: Requires two 12V marine batteries wired in series
- Control Compatibility: Compatible with Minn Kota wireless remote control; foot pedal available separately
- Mounting Compatibility: Compatible with standard Minn Kota mounting systems
