The Metal Eye Bolt CHC 8.8 Galvanized is a high-strength, corrosion-resistant fastener designed for secure attachment in various applications.
- Material: Galvanized steel, providing enhanced resistance to corrosion.
- Mechanical Strength: Class 8.8, indicating a minimum tensile strength of 800 N/mm² and a minimum yield strength of 640 N/mm².
- Standard Compliance: Manufactured according to DIN 912 standards, ensuring consistent quality and compatibility.
Technical Specifications
- Thread Dimensions:
- Diameter (d): Available in M4, M5, M6, M8, M10, M12, M14, and M16 sizes.
- Thread Pitch (p): Varies by diameter; for example, M4 has a pitch of 0.7 mm.
- Head Dimensions:
- Head Diameter (d₂): Specific dimensions depend on the thread size; for instance, M4 has a head diameter of 7 mm.
- Head Height (k): Varies by size; M4 has a head height of 4 mm.
- Socket Size (s): Corresponding to the hexagon socket size; for M4, the socket size is 3 mm.
- Length (L): Customizable based on application requirements.
Materials
- Galvanized Steel: Offers superior corrosion resistance, extending the fastener's lifespan in harsh environments.
Dimensions
| Thread Size (d) | Head Diameter (d₂) | Head Height (k) | Socket Size (s) | Length (L) |
|---|
| M4 | 7 mm | 4 mm | 3 mm | Customizable |
| M5 | 8.5 mm | 5 mm | 4 mm | Customizable |
| M6 | 10 mm | 6 mm | 5 mm | Customizable |
| M8 | 13 mm | 8 mm | 6 mm | Customizable |
| M10 | 16 mm | 10 mm | 8 mm | Customizable |
| M12 | 18 mm | 12 mm | 10 mm | Customizable |
| M14 | 21 mm | 14 mm | 12 mm | Customizable |
| M16 | 24 mm | 16 mm | 14 mm | Customizable |
Compatibility Information
This eye bolt is suitable for applications requiring a secure attachment point, such as marine hardware, rigging, and structural assemblies.
