Key Features:
- Ergonomic Design: Compact angle grinder with adjustable speed and the smallest handle circumference in its class, ensuring optimal ergonomics and reduced user fatigue.
- Enhanced Motor Performance: Equipped with the Metabo Marathon motor featuring patented dust protection, offering up to 20% more overload capacity and 50% more torque for extended service life and increased power.
- Variable Speed Control: Vario-Constamatic (VC) full-wave electronics with a thumbwheel allow for customized speed settings, maintaining consistent speeds under load for various materials.
- Quick and Tool-Free Disc Change: The M-Quick system enables fast, tool-free disc changes at the push of a button, enhancing efficiency.
- Safety Features: Metabo S-automatic mechanical safety clutch minimizes kick-back to the lowest level when the disc jams unexpectedly, ensuring maximum user safety and swift progress.
- Additional Protections: Includes electronic overload protection, soft start, and restart protection for enhanced safety and durability.
- Versatile Gear Housing: The gear housing can be unscrewed, rotated in 90° steps, and remounted for left-handed operation or cutting applications.
- Auto-Stop Carbon Brushes: Protects the motor by automatically stopping the grinder when the carbon brushes are worn, preventing potential damage.
Technical Specifications:
- Disc Diameter: 125 mm (5 inches)
- Rated Input Power: 1100 W
- Output Power: 640 W
- No-Load Speed: 2800 - 10,500 rpm
- Speed at Rated Load: 8800 rpm
- Torque: 3 Nm (26.6 in-lbs)
- Spindle Thread: M 14
- Handle Circumference: 193 mm (7.5594 inches)
- Weight (Without Power Cable): 2.1 kg (4.6 lbs)
- Cable Length: 4 m (13 ft)
- Vibration:
- Surface Grinding: 6 m/s² (uncertainty K = 1.5 m/s²)
- Grinding with Sandpaper: 2.5 m/s² (uncertainty K = 1.5 m/s²)
- Noise Emission:
- Sound Pressure Level: 93 dB(A)
- Sound Power Level (LwA): 104 dB(A) (uncertainty K = 3 dB(A))
Materials: The grinder is constructed with high-quality materials, including a durable gear housing and a robust motor housing, ensuring longevity and reliability.
Compatibility Information: The WEV 11-125 Quick Angle Grinder is compatible with standard 125 mm (5-inch) grinding and cutting discs with an M 14 spindle thread.
