Mersen 80A NH Fuse, NH00, 690V ac - Z320159
Reliable 80A NH Fuse for high rupture capacity and protection of power semi-conductors.
Manufacturer part number: Z320159
GTIN: 3605340358285
Only Ships to: France, Monaco For shipping outside these regions, please contact customer support.
Current Rating = 80A
Fuse Size = NH00
Voltage Rating = 690V ac
Fuse Standard = IEC 269.4, IEC 60269-4
Application Category = aR
Tag Width = 6mm
Fuse Speed = FF
High Rupture Capacity = Yes
Overall Length = 79mm
Body Length = 50mm
Body Width = 29.5mm
Body Height = 47.5mm
Fuse Dimensions = 50 x 29.5 x 47.5mm
DIN 43620. Protistor® fuses DIN 43620 size T00. Fuses with very high breaking capacity to protect power semi-conductors. Body equipped with a fusion striker capable of activating a micro-switch attached to the body. Order micro-switch separately, stock no. ; 448-3241 448-3241
