MEAN WELL LED Driver, 72V Output, 100W Output, 1.4A Output, Constant Current Dimmable - ELG-100-C1400A
High-efficiency Mean Well LED driver with 72V output and dimmable functionality for versatile applications.
Manufacturer part number: ELG-100-C1400A
Output Voltage = 72V
Maximum Output Power = 100W
Output Current = 1.4A
Output = 72 V dc @ 1400 mA
5. Mean Well ELG-100C Series Dimmable LED Driver. Mean Well ELG-100C series of constant current 100 W dimmable LED Driver, which also supports a high-voltage constant output. Thanks to a fan-less design, the ELG-100C series provides an efficiency rating of up to 91%. Constructed in a robust full metal housing to ensure suitability with a wide variety of applications. Fan-less design provides high efficiency rating. Wide operating temperature range. Rated to IP 65/67 depending on the option selected. Designed to provide the optimal flexibility for LED applications. Both Potentiometer and PWM signal dimming options available. Class 2 power unit. Built-in active PFC function. Typical applications include LED street lighting, architectural lighting, bay lighting ; floodlighting.
