The Mano glyc D63mm -1/1bars 1/4' radial is a radial pressure gauge designed for precise measurement of pressure in various applications.
- Glycerin-Filled Dial: The gauge is filled with glycerin, which dampens needle fluctuations caused by vibrations, ensuring stable and accurate readings.
- Stainless Steel Case: Constructed with a stainless steel case (ASTM A182 F304), the gauge offers enhanced durability and resistance to corrosion.
- Polycarbonate Glass: Equipped with a transparent polycarbonate glass cover, providing clear visibility of the dial while protecting the internal components.
- Male BSP Thread: Features a male BSP (British Standard Pipe) thread for secure and standardized connections.
- Temperature Range: Operates effectively within a temperature range of 0°C to +60°C, suitable for various environmental conditions.
Technical Specifications:
- Diameter: 63 mm
- Pressure Range: -1 to +1 bar
- Connection Type: Radial (bottom) connection
- Accuracy Class: Class 2.5
- Fluid Temperature Limit: Up to 60°C
Materials:
- Case: Stainless steel (ASTM A182 F304)
- Bourdon Tube: Brass, soldered with tin
- Connection: Brass
- Glass: Polycarbonate
Dimensions:
- Case Diameter: 63 mm
- Connection Size: 1/4 inch BSP male thread
Compatibility Information: This pressure gauge is suitable for measuring the pressure of non-corrosive gases or liquids that are not highly viscous and are not corrosive to copper and tin alloys. It is particularly adapted for devices subjected to high vibrations.
