Lovato ModuLo P1MB MCB, 1P, 40A Curve D, 230V AC, 60V DC, 10 kA Breaking Capacity - P1MB1PD40
The Lovato MCB 1P 40A Curve D provides reliable circuit protection with a 10 kA breaking capacity.
Manufacturer part number: P1MB1PD40
Availability: Out of stock
Only Ships to: France, Monaco, Italy For shipping outside these regions, please contact customer support.
Number of Poles = 1
Current Rating = 40A
Tripping Characteristics = Type D
Rated AC Voltage = 230V
Rated DC Voltage = 60V
Breaking Capacity at Maximum Voltage Rating = 10 kA
Range = ModuLo
Series = P1MB
Circuit Breaker Type = MCB
Length = 86.5mm
Mounting Style = DIN Rail Mount
Depth = 80mm
P1MB MCBs 1P. Miniature Circuit Breakers up to 63A with positive indication by flag window. Ratings 1 to 63A Tripping characteristics B, C and D Rated insulation voltage: 440V Rated impulse withstand voltage: 4kV Rated operating voltage: 230/400VAC DIN rail mounting Add-on blocks available
