Lewmar HTX 60 mm Block Double with Becket - Superior Control
Enhance the performance of your sailing yacht with the Lewmar HTX 60 mm Rigging Block Double with Becket. This high-quality block is specifically designed for demanding sailors looking for a combination of extreme strength, durability, and smooth operation under high load. Thanks to the integration of modern materials and proven design principles, this is the ideal hardware for modern lines with low stretch.
Designed for Maximum Load
The HTX series from Lewmar builds on the success of the Racing line but is translated into a robust construction for cruising sailors and competitions at any level. The cheeks are made from high-quality aluminium, providing excellent stiffness without adding unnecessary weight.
Why Choose the Lewmar 29196005?
This specific double block with becket offers the necessary versatility for complex delays in your rigging or mainsheet system. The side bearings are made of delrin, ensuring minimal friction, while the central shaft effortlessly absorbs heavy static loads.
Key Features
- Construction: Robust aluminium cheeks for optimal protection of the sheave.
- Bearing System: Equipped with side delrin bearings for smooth rotation.
- Versatility: Double sheave configuration including becket for extra delay.
- Application: Ideal for halyards, sheets, and other heavily loaded lines on yachts.
- Maintenance Friendly: Open design allowing salt and dirt to wash away easily.
Technical Specifications
The Lewmar 29196005-HTX is built to the highest standards in water sports. Below you will find the exact technical data:
PropertySpecificationModelLewmar HTX 60 mm Double with BecketArticle Number29196005-HTXSheave Diameter60 mmMaximum Line Diameter12 mmSafe Working Load (SWL)1100 kgWeight455 gramsMaterial CheeksAnodised Aluminium
