Key Features:
- Designed for 8mm outer diameter tubes
- 90-degree angle for efficient fluid or gas direction change
- Compression connection type for secure and leak-proof fittings
- Constructed from high-quality brass for durability and corrosion resistance
- Suitable for various applications, including chemical fluids, air, fuel, hydraulic oil, machining oil, and potable water
Technical Specifications:
- Material: Brass
- Fitting Shape: 90-degree elbow
- Connection Type: Compression
- Tube Size: 8mm outer diameter
- Maximum Operating Pressure: 1,450 psi
- Temperature Range: -40°F to 482°F (-40°C to 250°C)
- Compliance: Meets standards such as AFNOR, CETOP, CNOMO, ISO
Materials:
- Body: Brass
- Gasket: FKM (Fluorocarbon elastomer)
Dimensions:
- Overall Length: 28 mm
- Hex Size: 14 mm
Compatibility Information:
- Compatible with tubes made of aluminum, copper, and thermoplastic materials
- Suitable for use with various fluids and gases, including chemical fluids, air, fuel, hydraulic oil, machining oil, and potable water
Additional Details:
- Designed for easy installation and maintenance
- Provides a reliable and leak-proof connection in various piping systems
