Lascar EL-USB-4 Current Data Logger, USB, 1 Input Channel(s)

Number of Input Channels = 1
Measurement Parameters = Current
Interface Type = USB
Data Logger Type = Current
Power Source = Battery
Minimum Operating Temperature = -35°C
Maximum Operating Temperature = +80°C
Maximum Current Measurement = 20mA dc
Battery Life = 3 Yearsmm

Lascar Data LoggersThe Lascar EL-USB-4 standalone data logger measures and stores over 32,000 current loop readings over a 4mA to 20mA DC range at a resolution of 0.05mA DC. The user can easily set up the logger and view the downloaded data by plugging the data logger into a PC’s USB port and using the free EasyLog software. Data can then be graphed, printed and exported to other applications for a detailed analysis. The data logger is also issued with a 4mA to 20mA cap featuring a pair of screw terminals and measurement leads terminating in crocodile clips. Supplied with 1/2 AA battery, measurement leads and wall mount clip.Features and BenefitsThe current loop readings over a 4mA to 20mA DC range Current measurement accuracy is ±0.1°% Logging rates between 1 second and 12 hours Number of readings per channel is 32510 Immediate and delayed logging start User-programmable alarm thresholds Status indication via LEDs Battery life is up to 3 years Supplied with a 1/2AA lithium metal battery Export to Excel functionalityApplicationsOutside environmental data Process industry
