Key Features:
- Full bore design for minimal pressure loss
- Suitable for solids due to the absence of internal valves
- Corrosion-resistant stainless steel construction
- Complies with MIL-C-27487 standards
Technical Specifications:
- Connection Type: 1/2" BSP (Rp 1/2")
- Material: Stainless steel (1.4408)
- Seal Type: NBR (Nitrile Butadiene Rubber)
- Temperature Range: -10°C to +80°C
- Maximum Operating Pressure: 11 bar (160 psi)
- Dimensions:
- Plug Diameter: 24.3 mm
- Face to Face: 31.0 mm
Materials:
- Body and Cam: Stainless Steel EN 1.4408
- Seal: NBR
Compatibility Information:
- Compatible with 1/2" BSP threaded connections
- Suitable for use with various fluids, including water, compressed air, and saturated steam
Additional Details:
- Manufactured using the lost wax process
- Designed for applications requiring a secure and leak-proof connection
