The GRAB'N'SLIDE - Small Beam Anchor is a mobile anchorage device designed for securing to steel beams, providing a reliable point for fall arrest systems. It is suitable for beams with widths ranging from 70 mm to 150 mm.
- Adjustable Fit: Accommodates beam widths from 70 mm to 150 mm, ensuring versatility across various beam sizes.
- High Breaking Strength: Offers a minimum breaking strength exceeding 23 kN, providing robust support for fall arrest systems.
- Compliance: Conforms to EN 795:2012 Type B standards and the ATEX Directive 2014/34/EU, ensuring safety and reliability.
- Materials: Constructed from durable aluminium and brass, combining lightweight properties with strength.
- Ease of Use: Designed for quick and easy installation and removal, facilitating efficient setup and takedown.
Technical Specifications
- Beam Compatibility: Suitable for IPN and IPE beams with widths between 70 mm and 150 mm.
- Breaking Strength: Minimum breaking strength greater than 23 kN.
- Compliance Standards: EN 795:2012 Type B and ATEX Directive 2014/34/EU.
- Materials: Aluminium and brass.
- Weight: Approximately 1.6 kg.
Materials
- Aluminium: Provides a lightweight yet strong structure.
- Brass: Offers corrosion resistance and durability.
Dimensions
- Adjustable Range: Fits beams with widths from 70 mm to 150 mm.
- Weight: Approximately 1.6 kg.
Compatibility Information
- Beam Types: Compatible with IPN and IPE steel beams.
- Standards Compliance: Meets EN 795:2012 Type B and ATEX Directive 2014/34/EU standards.
