Key Features:
- Crimping Dies: Equipped with two crimping dies for end caps on Bowden cable sheaths and end ferrules for traction cables.
- Comfortable Design: Features a slim, ergonomic design with an internal opening spring for ease of use.
- Adjustable Joint: Bolted joint allows for precise blade guidance and is re-adjustable.
- High Leverage: Designed to reduce manual effort during cutting tasks.
- Cutting Edge Hardness: Approximately 64 HRC for enhanced durability.
Technical Specifications:
- Cutting Capacities:
- Wire Rope (maximum 1600 N/mm²): Up to 5.0 mm diameter
- Medium Hard Wire: Up to 4.0 mm diameter
- Piano Wire: Up to 2.5 mm diameter
- Round Steel Bar (maximum 1200 N/mm²): Up to 4.0 mm diameter
- Material: Forged from high-performance chrome vanadium steel, oil-hardened in multiple phases.
- Handle Coating: Plastic-coated handles for a secure grip.
- Weight: Approximately 310 grams.
- Dimensions: 190 mm (length) x 60 mm (width) x 20 mm (height).
Materials:
- Steel Type: Chrome vanadium special steel, oil-hardened.
Dimensions:
- Length: 190 mm
- Width: 60 mm
- Height: 20 mm
Compatibility Information:
Suitable for cutting wire ropes, multi-core cables, and round steel bars up to specified diameters.
Additional Details:
- REACH Compliance: Does not contain SVHC (Substances of Very High Concern).
- RoHS Compliance: Not applicable.
