- Key Features:
- Adjustment at the touch of a button directly on the workpiece.
- Fine adjustment for optimum adaptation to different sizes of workpieces and a comfortable gripping position.
- Self-locking on pipes and nuts: no slipping off the workpiece and low hand force required.
- Gripping surfaces with special hardened teeth, teeth hardness (approx. 61 HRC): low wear and reliable gripping.
- Box-joint design: high stability because of double guide.
- Reliable catching of the hinge bolt: no unintentional shifting.
- Pinch guard prevents operators' fingers from being pinched.
- Slim, two-color multi-component handles for better handling and easier transport.
Technical Specifications:
- Length: 10 inches (250 mm)
- Weight: 366 grams
- Material: Chrome vanadium electric steel, forged, multi-stage oil-hardened
- Handle Type: Slim multi-component
- Gripping Surface: Serrated
- Surface Finish: Polished jaws, grey atramentized
- Joint Type: Box-joint
- Number of Adjustment Positions: 25
- Max Jaw Opening:
- Round Pipe: 2 inches (50 mm)
- Hex: 1 3/4 inches (46 mm)
- Working Capacity: 2 inches (50 mm)
- DIN Standard: DIN ISO 8976
- REACH Compliant: Does not contain SVHC
- RoHS Compliant: Not applicable
Materials:
Chrome vanadium electric steel, forged, multi-stage oil-hardened
Dimensions:
- Length: 10 inches (250 mm)
- Width: 2 1/8 inches (54 mm)
- Height: 3/4 inch (19 mm)
Compatibility Information:
Suitable for gripping flat, round, and angled components. Ideal for use on pipes and nuts up to 2 inches (50 mm) in diameter and nuts up to 1 3/4 inches (46 mm) in size.
Additional Details:
- The box-joint design provides high stability due to the double guide.
- The reliable catching of the hinge bolt prevents unintentional shifting.
- The pinch guard prevents operators' fingers from being pinched.
- The slim, two-color multi-component handles offer better handling and easier transport.
