Keysight Technologies RF Switch, SPDT, 18GHz Max, >80.0dB Isolation, 200ns, 50O Output - P9400C
High-performance RF switch with >80dB isolation and 200ns switching speed for optimal test setups.
Manufacturer part number: P9400C
Switch Configuration = SPDT
Switching Speed = 200ns
Port to Port Isolation = >80.0dB
Maximum Insertion Loss = 4.2dB
Return Loss = 10dB
Output Impedance = 50O
Maximum Frequency = 18GHz
The Keysight Technologies P9400C solid state PIN diode transfer switch offers outstanding performance in terms of port-to-port isolation, switching speed, and low insertion loss over a broad operating frequency range of 100 MHz to 18 GHzBroad operating frequency range provides flexibility in test setup Minimizes crosstalk with exceptionally high port-to-port isolation Optimizes system dynamic range with low insertion loss Eliminates the need for external drivers with an integrated TTL c
