Ideal for naval installations requiring high safety standards, this exhaust and cooling hose offers excellent flexibility and durability in demanding marine environments. The spiral rubber provides a reduced bending radius, facilitating assembly and preventing premature duct restrictions.
Technical Specifications
- Inner diameter: 90 mm
- Material: High-performance rubber with spiral reinforcement
- Temperature range: -30ºC to +100ºC
- Minimum bend radius: 1 to 1.5 times the inner diameter
- Standards: SAE J 2006 – 2003 R2, ISO 13363 – 2004 T-2 Class B
- Certification: RINA CE 0474, Lloyd’s Register 96/00/127
- Format: Sold by the meter
Advantages
- Suitable for industrial applications and recreational vessels.
- Internationally certified and resistant to marine wear.
- Easy adaptation to complex routing.
Applications and Compatibility
- Exhaust systems for marine diesel and gasoline engines.
- Sea water cooling pipes.
- Compatible with standard nautical fittings of 90 mm.
Installation and Maintenance Tips
- Regular inspections to prevent cracks or wear.
- Install respecting minimum bending radii.
- Use high-quality clamps, preferably stainless steel AISI 316.
Technical Specifications Table
| Diameter (mm) | 90 |
|---|
| Material | Reinforced rubber |
|---|
| Temperature Range (°C) | -30 to +100 |
|---|
| Standards | SAE J2006, ISO 13363 |
|---|
| Certifications | RINA, Lloyd’s Register |
|---|
