Honeywell HDLS Series Limit Switch, 2NO/2NC, DPDT, Stainless Steel Housing, 600V ac Max, 10A Max - LS2A4L

Pole and Throw Configuration = DPDT
Normal State Configuration = 2NO/2NC
Maximum Current = 10A
Housing Material = Stainless Steel
Maximum AC Voltage = 600V
Maximum DC Voltage = 250V
Connection Type = 3/4 in NPT
Series = HDLS
Action Type = Snap Action
Length = 122.96mm
Width = 1.875in

UL Listed, file E37138. CSA Certified, file LR57326. NEMA 1, 3, 3R, 4 4X, 6, 6P, and 13. HDSL Stainless Steel Limit Switches. These switches are designed for use in highly corrosive environments such as petrochemical plants, food processing plants, shipboard, and dockside locations. The type 316 cast stainless steel body is designed to minimize crevices where particles could become trapped. The actuator, operating head, and screws are also stainless steel. All seals are fluorocarbon to provide excellent chemical resistance and to withstand operating temperatures up to 121°C (250°F) and pressurised steam cleaning. Preleaded and epoxy filled versions are also available. Interchangeable with standard HDLS mounting. Corrosion-resistant stainless steel non-plug in body, head and rotary shaft Stainless steel levers Fluorocarbon seals Operating temperature range –12°C to +121°C (10°F to +250°F)
