Key Features:
- Efficient Filtration: Utilizes a reinforced polyester cartridge to effectively remove suspended particles from pool water.
- Corrosion-Resistant Construction: The filter body is injected with Duralon, ensuring resistance to corrosion and extending the filter's lifespan.
- Easy Maintenance: Features a butterfly lock system for straightforward assembly and disassembly, facilitating easy access to the cartridge for cleaning.
- User-Friendly Design: Equipped with a pressure gauge, purge valve, and drain plug for convenient operation and maintenance.
Technical Specifications:
- Flow Rate: 11 m³/h
- Filtration Capacity: 15 to 20 microns
- Maximum Working Pressure: 3.5 bars
- Inlet/Outlet Size: 1"1/2
- Filtered Area: 4.6 m²
Materials:
- Cartridge Material: Reinforced polyester for enhanced durability and filtration efficiency.
- Filter Body Material: Injected Duralon, providing a corrosion-resistant structure.
Dimensions:
- Height (A): 235 mm
- Width (B): 203 mm
- Depth (C): 267 mm
- Length (D): 749 mm
- Base Diameter (E): 117 mm
- Base Height (F): 57 mm
Compatibility Information:
This filter is compatible with pools requiring a flow rate of 11 m³/h and is designed to work efficiently with standard pool systems.
Additional Details:
- Warranty: 2 years
- Maintenance: Cleaning is performed by removing the cartridge and washing it with a hose, eliminating the need for backwashing and reducing water waste.
- Environmental Considerations: The design minimizes water usage during maintenance, making it an environmentally friendly option.
