Hager MCCB 4P 125A, Breaking Capacity 25 kA, DIN Rail Mount - HHA126H

Manufacturer: Hager

Ensure electrical safety with the Hager MCCB 4P 125A, featuring thermal-magnetic tripping and DIN rail mounting.

Manufacturer part number: HHA126H

GTIN: 3250613130923

Vendor: YACHTNEEDS-RS

€1060.97

Qty:

i h

Ships to: France, Monaco

Series = HHA
Number of Poles = 4
Current Rating = 125A
Breaking Capacity at Maximum Voltage Rating = 25 kA
Rated AC Voltage = 220/415V
Mounting Style = DIN Rail Mount
Length = 99.5mm
Width = 107.1mm
Depth = 130mm
Tripping Mechanism = Thermal-Magnetic

Conforms to NF EN60947-2. Hager X160 Moulded Case Circuit Breakers. Features and Benefits. Adjustable thermal and fixed magnet 3P3D and 4P4D Access to mechanical test button on cover Lockable cover protects MCCB settings Integrated padlocking handle Ø 4mm DIN Rail mountable
