Key Features:
- Non-stick design for maintenance-free operation
- Full flow capacity
- Suitable for nautical applications
Technical Specifications:
- Thread Size: 3/4 inch
- Flow Rate at 1 bar: 39,000 liters per hour
- Dimensions:
- A (Connection Size): 16.3 mm
- L (Length): 73 mm
- H (Height): 85 mm
- V (Valve Body Diameter): 58 mm
- SW (Wrench Size): 31 mm
Materials:
- Body: Bronze
- Gaskets: Neoprene
- Handwheel: Thermoplastic
Compatibility Information:
- Designed for use in nautical applications
Additional Details:
- RINA approved
- Maintenance-free internal mechanism due to protective neoprene coating
- Polyamide 6 reinforced nylon handwheel with operating lever for ease of use
