Key Features:
- Nickel-plated brass construction for enhanced durability and corrosion resistance.
- 3-way diverter design allows for efficient flow direction control without the need for additional tees or valves.
- Female BSP parallel ISO 228 threads (3/8") on all ports for easy integration into existing piping systems.
Technical Specifications:
- Thread Type: G = EN 10226/1 (BS 21) BSPT
- Pressure Rating: PN 16
- Flow Capacity: 9000 liters per hour at 1 bar pressure
Materials:
- Body: Nickel-plated brass
- Threads: Brass
Dimensions:
- A: 11.4 mm
- F: 10 mm
- H: 48 mm
- L: 52 mm
- G: 3/8"
- M: 110 mm
Compatibility Information:
- Designed for use with standard 3/8" BSP parallel threaded piping systems.
- Suitable for applications requiring flow diversion without the complexity of multiple valves.
Additional Details:
- Ideal for marine and plumbing applications where space and efficiency are critical.
- Provides a streamlined solution for directing flow in one direction at a time, enhancing system performance.
