Gloxco - Aluminium Camlock Coupling Type B, 1/2" x 3/4" - CAM-0507-B-AL

Manufacturer: Gloxco
Quick-connect aluminium camlock coupling for efficient fluid transfer.
Manufacturer part number: CAM-0507-B-AL
Vendor: Deal Marine
*
Availability: Out of stock
€12.72
i h
  • Key Features:
    • Quick connect and disconnect without the need for specialized tools.
    • Lightweight design for ease of handling.
    • Good abrasion resistance.
    • Fair corrosion and chemical resistance.
    • Economical cost.
  • Technical Specifications:
    • Type: Type B Camlock Coupling.
    • Size: 1/2" Female Camlock Coupler x 3/4" Male BSP Thread.
    • Material:
      • Body: Aluminum alloy.
      • Handle and finger rings: Stainless steel.
      • Seal: NBR (Buna-N) rubber.
    • Thread Type: Male BSP (British Standard Pipe) thread.
    • Maximum Operating Pressure: 250 PSI.
    • Temperature Range: Suitable for use with water, hydraulic oils, coolants, gasoline, and other petroleum products.
  • Materials:
    • Body: Aluminum alloy, known for its lightweight and corrosion-resistant properties.
    • Handle and Finger Rings: Stainless steel, providing durability and resistance to corrosion.
    • Seal: NBR (Buna-N) rubber, offering resistance to fuel, oil, and other chemicals.
  • Dimensions:
    • Overall Length: Approximately 2.5 inches.
    • Coupler Length: Approximately 1.625 inches.
    • Distance Across Closed Cam Arms: Approximately 2.4375 inches.
    • Distance Across Open Cam Arms: Approximately 5.1875 inches.
  • Compatibility Information:
    • The 1/2" Female Camlock Coupler is designed to connect with a 1/2" Male Camlock fitting.
    • The 3/4" Male BSP Thread is compatible with a 3/4" Female BSP threaded connection.
  • Additional Details:
    • This camlock coupling is suitable for applications involving water, hydraulic oils, coolants, gasoline, and other petroleum products.
    • It is not suitable for use with compressed air or steam.
