Gems Sensors FS-200E-A Series Shuttle Flow Sensor for Liquid, 3 L/min Min, 22.5 L/min Max - 020-3489

Gems Sensors Flow SwitchThe Gems Sensors FS-200E-A series flow switch has a liquid flow rate of 3L/min to 22.5L/min. This flow switch is a highly efficient device for accurate flow detection. It has 1% repeatability and is available in European G1in port size. The durable construction delivers long life repeatability in either water or oil. On the other hand, the design of large flow paths keeps the pressure drop low. Thus, it is ideal for detection of flow in high volume lubrication, cooling, or process applications.Features and BenefitsPipe diameter range is 1in Connection type is 1 BSP Plug type connector Primary construction material is bronze Setting type: adjustable Operating pressure is 27bar Pressure drop is 0.2bar SPDT switching function Connection type is 1 BSPApplicationsProtect bearings or gears: oil separators, fuel systems, pumps, compressors and presses Electronics or machinery: heat exchangers, semiconductor manufacturing equipment, induction furnaces and radio transmitters Process systems: water filtration and reverse osmosis, chlorinates, de-icers, sterilisers and evaporatorsCertificationsIP65 rated
