Garmin offers a comprehensive range of NMEA 2000 cables and connectors designed to build and expand your NMEA 2000 network on your boat. These components ensure reliable communication between marine devices, enhancing your boating experience.
- NMEA 2000 Power Cable: Connects the NMEA 2000 network to a 12 Vdc power source. Includes a 2-meter (6.5-foot) cable with a 3 A fuse.
- NMEA 2000 Backbone/Drop Cables: Available in lengths of 0.3 meters (1 foot), 2 meters (6.5 feet), 4 meters (13 feet), 6 meters (20 feet), and 10 meters (33 feet). Cables up to 6 meters (20 feet) can serve as either backbone or drop cables; those longer than 6 meters are suitable only as backbone cables.
- NMEA 2000 Right-Angle Backbone/Drop Cable: Available in lengths of 0.3 meters (1 foot) and 2 meters (6.5 feet). Ideal for connecting devices with limited clearance for rear connectors.
- Removable Screw Collar for NMEA 2000 Connector: An 11 mm split connector that allows routing cables without drilling large holes in your boat.
- NMEA 2000 Power Isolation Connector (Engine): Prevents a device from providing power to the NMEA 2000 network, ensuring proper power distribution.
Technical Specifications:
- Cable Lengths: 0.3 meters (1 foot), 2 meters (6.5 feet), 4 meters (13 feet), 6 meters (20 feet), and 10 meters (33 feet).
- Power Cable Fuse: 3 A fuse included.
- Connector Type: NMEA 2000 micro connectors.
Compatibility Information:
Garmin NMEA 2000 cables and connectors are compatible with Garmin NMEA 2000 devices. If integrating with existing NMEA 2000 networks, ensure compatibility with NMEA 2000 micro connectors. Existing networks may use NMEA 2000 mini connectors, which are larger and require a converter or adapter for connection.
