The Garmin ECHOMAP UHD2 72sv is a versatile GPS sonar combo designed to enhance your boating and fishing experience. This 7-inch chartplotter features a bright, sunlight-readable touchscreen display, providing clear and sharp visuals of your surroundings. It comes equipped with a built-in worldwide basemap and supports various Garmin cartography options, including Navionics+™, Navionics Vision+™, BlueChart® g3 coastal charts, and LakeVü™ g3 inland maps.
- Display: 7-inch WVGA touchscreen with a resolution of 800 x 480 pixels, offering a clear and intuitive interface.
- Sonar Capabilities: Supports Garmin traditional sonar, ClearVü™, and SideVü™ scanning sonars, providing detailed imaging of underwater structures and fish.
- Connectivity: Built-in Wi-Fi® allows wireless sharing of sonar data, waypoints, and routes with another ECHOMAP UHD2 chartplotter.
- Mapping Support: Compatible with Garmin Navionics+™, Navionics Vision+™, BlueChart® g3, and LakeVü™ g3 maps, offering comprehensive navigation options.
- ActiveCaptain® Integration: Pair with the free ActiveCaptain® app on your compatible smartphone for access to OneChart™, software updates, and more.
Technical Specifications:
- Material: Polycarbonate plastic
- Water Rating: IEC 60529 IPX7
- Temperature Range: From -20°C to 55°C (-4°F to 131°F)
- Input Voltage: 9 to 18 Vdc
- Fuse: 3 A, fast-acting (included)
- Memory Card: 1 microSD™ card slot; supports up to 1 TB card size
- Wireless Frequency: 2.4 GHz at 18.7 dBm maximum
- Sonar Frequencies: Traditional CHIRP: 50/77/83/200 kHz; Garmin ClearVü™ CHIRP: 260/455/800/1000/1200 kHz; Garmin SideVü™ CHIRP: 260/455/800/1000/1200 kHz
- Sonar Transmit Power (RMS): 500 W
- Sonar Depth: Up to 701 m (2,300 ft.) at 77 kHz
- Dimensions: Device and cradle only: 206 x 131 x 67 mm (8 1/8 x 5 3/16 x 2 5/8 in.); In bail mount with sun cover: 244 x 155 x 99 mm (9 5/8 x 6 1/8 x 3 7/8 in.)
- Display Size: 155 x 87 mm (6 1/8 x 3 7/16 in.) with a 178 mm (7 in.) diagonal
- Weight: 0.8 kg (1.8 lb.)
- Max. Power Draw: 18.3 W
- Typical Current Draw at 12 Vdc (RMS): 1.53 A
- Max. Current Draw at 12 Vdc (Peak): 3.2 A
- Compass-Safe Distance: 28 cm (11 in.)
Constructed with durable polycarbonate plastic for longevity and resilience.
Compatible with Garmin Navionics+™, Navionics Vision+™, BlueChart® g3, and LakeVü™ g3 maps. Supports wireless sharing of sonar data, waypoints, and routes with another ECHOMAP UHD2 chartplotter.
