Finder DIN Rail Latching Power Relay, 12V ac/dc Coil, 8A Switching Current, SPDT - 13.12.0.012.0000
Reliable 12V AC/DC latching power relay for efficient switching in various applications.
Manufacturer part number: 13.12.0.012.0000
GTIN: 8012823336633
Availability: Out of stock
Only Ships to: France, Monaco For shipping outside these regions, please contact customer support.
Coil Voltage = 12V ac/dc
Contact Configuration = SPDT
Mounting Type = DIN Rail
Switching Current = 8A
Number of Poles = 2
Latching = Yes
Terminal Type = Screw
Maximum Switching Voltage AC = 400V ac
Length = 17.5mm
Coil Power = 2.5W
Series = 13 Series°C
Maximum Switching Power AC = 2 kVA
13.11 ; 13.12 Series Call and Reset Relays. 13.11 ; 13.12 series call relays with reset command, rail mounted with 1 or 2 pole, respectively. Reset command suitable for residential and commercial applications: public bathroom, hospital, hotel 35 mm rail (EN 60715) or flange mount 17.5 mm wide Operating temperature range: -10 ºC to +60 ºC IP 20 protection category
