Finder 58 Series Interface Relay, DIN Rail Mount, 24V dc Coil, 4PDT, 4-Pole - 58.34.9.024.0050SMA

Coil Voltage = 24V dc
Contact Configuration = 4PDT
Mounting Type = DIN Rail
Series = 58 Series
Minimum Input Voltage = 19.2V
Switching Voltage = 250V
Depth = 86.9mm
Height = 78.4mm
Length = 27mm
Contact Material = Silver Alloy
Input Current = 40mA
Dimensions = 15.8 x 75.3 x 78.6mm

Finder Interface Relay ModuleThe Finder interface relay module is an ideal interface for PLC and electronic systems device equipped with a 24VDC coil and a 4PDT 4 C/O contact configuration. This interface relay works as a coupling element used to send control signals to and from a PLC. The high number of approvals make it useful for many applications around the world. It offers a high-density solution for smaller electrical cabinets and other industrial applications thus, optimising your panel installation. This solid-state relay module has a small footprint that makes it ideal for applications where space-saving is essential.Features and BenefitsThe contact rated voltage is 250VAC and switching current of 7A Instant ejection of relay using plastic retaining clip Supply status indication and EMC coil suppression module Operating temperature ranges from -40°C to 70°C AgNi Cadmium free contacts Screw type terminal connection DIN rail type mountingApplicationsPackaging machines Shipyards Textile machines Carousel warehouses Panels for electrical distribution Hoists and cranes Wood-processing machines Industrial process control Motor control applications Electrical isolation Signal matching between electronic controlsCertificationsIP20 rated UL approved CE certified VDE certified CSA certified EAC certified cRUus certified
