Festo Clamping Piece for EV - EV-20/120-5

Festo Clamping Piece - EV Series - EV-20/120-5 By providing a reliable pneumatic grip and constant clamping pressure, this clamping piece from Festo enhances workplace safety. Its automated gripping action also removes the risk of manual error and improves user efficiency. The compact unit delivers a controlled airflow for smooth operation and has a gripping force thats easy to reset. As its hermetically sealed, this component is suitable for use in industrial applications where dust and dirt are present.Features and Benefits• Block shape clamping piece • Die-cast aluminium housing • Operating pressure range of 2 bar to 6 bar • M5 pneumatic connection • Stroke size of 5 mm • Clamping area of 20 mm x 120 mm • Pressure chamber equipped with a diaphragm • Through-hole mount type • Can be assembled in any position • Ambient temperature range of -20°C to +40°C Range Information • The range of Festo EV clamping modules is designed for clamping strokes against a stop • The units feature a flat design and a compact, rodless cylinder • Festo also provides pressure plates and foot mounting accessories as part of the EV range • This series includes both round and elongated clampsCertificationsISO8573-1:2010
