Key Features:
- Designed for use with water, compressed air, and saturated steam.
- Operating temperature range: -10°C to +80°C.
- Constructed with an aluminium body for lightweight and corrosion resistance.
- Equipped with BSP threaded and tapped connections for secure fittings.
- Female camlock design for quick connect and disconnect without specialized tools.
Technical Specifications:
- Material: Aluminium body with brass handles.
- Seal Material: Nitrile rubber (NBR) seal.
- Thread Type: BSPP parallel threaded end.
- Maximum Operating Pressure: 10 bar (150 PSI).
- Manufacturing Standard: A-A-59326D (previously MIL-C-27437).
- Compatibility: Compatible with all other camlocks to the same standard.
Compatibility Information:
- Compatible with other camlocks adhering to the A-A-59326D standard.
- Suitable for connecting to male BSPT taper threaded ends.
Additional Details:
- Not suitable for compressed air or gas applications.
- Designed for low-pressure liquids, powders, and granules.
- Quick connect/disconnect fittings requiring no specialized tools.
