FAG 2212-2RS-TVH Self Aligning Ball Bearing- Both Sides Sealed 60mm I.D, 110mm O.D
Experience enhanced performance with FAG's self-aligning ball bearing, designed for high radial loads and angular misalignments.
Manufacturer part number: 2212-2RS-TVH
Inside Diameter = 60mm
Outside Diameter = 110mm
Race Width = 28mm
Ball Bearing Type = Self Aligning Ball Bearing
Sealing Arrangement = Both Sides Sealed
Bearing Clearance = CN
Material = Steel
Ball Material = Steel
Cage Material = Polyamide
Number of Rows = 2
Static Load Rating = 11.5kN
Dynamic Load Rating = 30.5kN
Bore Type = Parallel
Bearing Series = 2 Light
Partial Bearing Code = 2212
If there is skewing between the outer and inner ring (for the compensation of angular misalignments) For bearing arrangements with high radial loads For higher speeds on account of their point contact, than barrel roller bearings with line contact Where bearings with the above-mentioned characteristics are expected to run more quietly and at lower temperatures, even at high speeds
