FAG 2200-2RS-TVH Self Aligning Ball Bearing- Both Sides Sealed 10mm I.D, 30mm O.D
Experience enhanced performance with FAG's self-aligning ball bearing, designed for high radial loads and speeds.
Manufacturer part number: 2200-2RS-TVH
Inside Diameter = 10mm
Outside Diameter = 30mm
Race Width = 14mm
Ball Bearing Type = Self Aligning Ball Bearing
Sealing Arrangement = Both Sides Sealed
Bearing Clearance = CN
Material = Steel
Ball Material = Steel
Cage Material = Plastic
Number of Rows = 2
Static Load Rating = 1.19kN
Dynamic Load Rating = 5.7kN
Bore Type = Parallel
Bearing Series = 2 Light
Partial Bearing Code = 2200
If there is skewing between the outer and inner ring (for the compensation of angular misalignments) For bearing arrangements with high radial loads For higher speeds on account of their point contact, than barrel roller bearings with line contact Where bearings with the above-mentioned characteristics are expected to run more quietly and at lower temperatures, even at high speeds
