FAG 126-TVH Self Aligning Ball Bearing- Open Type 6mm I.D, 19mm O.D
Experience enhanced performance with FAG's self-aligning ball bearing, designed for high radial loads and speeds.
Manufacturer part number: 126-TVH
Inside Diameter = 6mm
Outside Diameter = 19mm
Race Width = 6mm
Ball Bearing Type = Self Aligning Ball Bearing
Sealing Arrangement = Open Type
Bearing Clearance = CN
Material = Steel
Ball Material = Steel
Cage Material = Polyamide
Number of Rows = 2
Static Load Rating = 480N
Dynamic Load Rating = 2.6kN
Bore Type = Parallel
Bearing Series = 2 Light
Partial Bearing Code = 126
If there is skewing between the outer and inner ring (for the compensation of angular misalignments)For bearing arrangements with high radial loadsFor higher speeds on account of their point contact, than barrel roller bearings with line contactWhere bearings with the above-mentioned characteristics are expected to run more quietly and at lower temperatures, even at high speeds
