Europa EUC3P EUC MCB, 3P, 2A Curve C, 230V AC, 10 kA Breaking Capacity - EUC3P2C
Reliable 3-pole MCB with 2A rating and 10 kA breaking capacity for enhanced safety.
Manufacturer part number: EUC3P2C
Only Ships to: France, Monaco For shipping outside these regions, please contact customer support.
Number of Poles = 3
Current Rating = 2A
Tripping Characteristics = Type C
Rated AC Voltage = 230 V, 400V
Breaking Capacity at Maximum Voltage Rating = 10 kA
Range = EUC3P
Series = EUC
Circuit Breaker Type = MCB
Length = 54mm
Mounting Style = DIN Rail Mount
Depth = 87mm
Model Number = EUC3P2C
IEC 60898, EN 60898. CE, SEMKO. Europacomponents MCBs. This range of MCB's are suitable for fitting into consumer units, they have been fully tested and conform to the relevant standards to ensure safety, protection and reliability. From 6A to 63A Terminal capacity: 1mm2 to 25mm2 Operating temperature -5° to 40°C 35mm DIN Rail mounting IP20
