Europa Contactor, 24 V ac Coil, 4-Pole, 25 A, 4 kW, 4NC, 400 V ac - EUC2-25-4NCB
Efficient 4-pole contactor with 24V AC coil, perfect for power control in various applications.
Manufacturer part number: EUC2-25-4NCB
Availability: Out of stock
Only Ships to: France, Monaco For shipping outside these regions, please contact customer support.
Coil Voltage = 24 V ac
Number of Poles = 4
Contact Voltage Rating = 400 V ac
Contact Current Rating = 25 A
Power Rating = 4 kW
Normal State Configuration = 4NC
Terminal Type = Screw
Length = 36mm
Depth = 68mm
Pole and Throw Configuration = 4PST
Modular contactors should be separated from other components using blanking modules to allow for heat dissipation. Europacomponents EUC2 Series Modular Contactor. Europa Components EUC2 series 4 pole modular contactors. These units are DIN Rail mounted and designed for installation in consumer units and three phase distribution boards. Ideal for heating lighting and building service type applications. 4 Pole Operating temperature: -5°C to 40°C 35mm DIN Rail mounting Maximum cable capacity main terminals: 10 mm² Maximum cable capacity coil terminals: 2.5 mm²
