Key Features:
- Universal Compatibility: Designed for 12V systems, suitable for various marine applications.
- Fuse Protection: Equipped with a 15A glass fuse (6.3 x 32 mm) to safeguard against overcurrent.
- Voltage Indicator: Integrated light to indicate voltage presence.
- Secure Connection: Features a locking mechanism that ensures a firm connection when the male plug's pins are pressed against the triangular markings on the female socket. To release, simply rotate the plug a quarter turn.
Technical Specifications:
- Maximum Current: 15A at 12V
- Fuse Type: Glass fuse, 6.3 x 32 mm
- Voltage Indicator: Integrated light
- Connection Type: Screw terminal
Materials:
- Body: Durable ABS plastic
- Contacts: Chrome-plated brass
Compatibility Information:
Compatible with Euromarine's 12V female sockets, ensuring a secure and waterproof connection.
Additional Details:
- Locking Mechanism: The plug locks into place when the male plug's pins are pressed against the triangular markings on the female socket. To unlock, rotate the plug a quarter turn.
- Installation: Connection is made via screw terminals, allowing for a secure and reliable setup.
