ETA Thermal Circuit Breaker - 2210 Single Pole 277, 480V Voltage Rating DIN Rail Mount, 500mA Current Rating - 2210-T210-K0M1-H121-0.5A
Ensure reliable circuit protection with the ETA Thermal Circuit Breaker, designed for precision applications.
Manufacturer part number: 2210-T210-K0M1-H121-0.5A
GTIN: 5059045892915
Current Rating = 500mA
Number of Poles = 1
Voltage Rating = 277, 480V
Width = 12.5mm
Series = 2210
Tripping Mechanism = Thermal-Magnetic
Reset Actuator Type = Toggle Switch
Rated AC Voltage = 277,480V
Mounting Style = DIN Rail Mount
Circuit Breaker Type = Thermal Magnetic Circuit Breakermm
UL, CSA, VDE, BV, LRoS. For Precision Applications, 2210 Series. Overload and short circuit protecting, DIN rail mounting, time delay type thermal-magnetic single-pole CBE, suitable for process control, telecom and other professional/precision applications, etc. Toggle operated trip-free mechanism Auxiliary contact (NC) for remote signalling of contact breaker status Narrow profile enables high density packaging Compatible with Top-hat and G-profile DIN-rail Compatible with modular DIN 43880 housings IEC Classification S/TM 20 - 30 second tripping time Typical life - 5000 Ops.
