Key Features:
- Self-Priming: Capable of self-priming up to 4 meters, ensuring efficient operation.
- Silent Operation: Designed for ultra-quiet performance, making it suitable for residential and public swimming pools.
- Compatibility: Compatible with both fresh and saltwater pools.
- High-Capacity Pre-Filter: Equipped with a large pre-filter to capture larger debris before water reaches the filtration system.
- Durability: Constructed with robust materials for enhanced longevity.
- Easy Maintenance: Features an easy opening and closing system for convenient maintenance.
- Protection and Insulation: IP 55 protection rating and Class F insulation for reliable and safe operation.
- Warranty: Comes with a 2-year warranty.
Technical Specifications:
- Motor Type: Asynchronous, two-pole motor.
- Electrical Isolation: Class F.
- Protection Rating: IP 55.
- Service Factor: S1 (continuous service).
- Materials:
- Pump Body, Foot, Impeller, Diffuser: Technopolymer.
- Motor Shaft: Stainless steel AISI 431.
- Mechanical Seal: Graphite and aluminum oxide.
- Motor Casing: Aluminum.
- O-Rings: NBR/EPDM.
- Suction and Discharge Connections: Glue union with a diameter of 63 mm.
- Maximum Suction Height: 4 meters.
- Maximum Water Temperature: 40°C.
Dimensions:
The Silen S2 series includes various models with different power ratings and dimensions. For example, the Silen S2 100 model has the following dimensions:
- Length (A): 624 mm
- Width (B): 222 mm
- Height (C): 272 mm
- Discharge Diameter (D): 63 mm
- Suction Diameter (E): 63 mm
- Motor Shaft Length (F): 268 mm
- Motor Shaft Diameter (H): 63 mm
- Total Height (I): 327 mm
Compatibility Information:
The Silen S2 is compatible with both fresh and saltwater pools, including those using salt chlorination systems. It is designed to handle water temperatures up to 40°C. The pump is suitable for various pool sizes and can be used in both residential and public swimming pools.
